TRAILBLAZER™ Heavy-Duty
STRAIGHT BLADE SNOWPLOWS
Quick Specs
- 6' Blade Width
- 261 lb Approx. Weight
- 5'4" Full Angle Plowing Width
- Fits: Full Sized UTVs & Tractors
Verify compatibility and part number information
MAXIMUM CLEARANCE.
ZERO COMPROMISE.
The FISHER® TRAILBLAZER™ Heavy-Duty Straight Blade bridges the gap between agility and raw strength by utilizing the same commercial grade technology found in our largest plows. Built from high-strength, low-alloy steel, these straight blades deliver the structural integrity and durability required for long winter shifts. Whether you’re navigating narrow sidewalks or clearing expansive walking paths, the TRAILBLAZER allows you to clear properties with ease and speed.
Unique Features
Blade Construction
- 23½” tall moldboard available in 6′ width
- 14-gauge, powder coated steel
- ¼” x 5″ high-carbon steel cutting edge comes standard to increase the wear resistance of your blade
- 70-degree attack angle ensures a clean scrape and back drag
- Easy accessory installation with pre-punched blade
Structural Reinforcement
- 4 vertical ribs eliminate blade twisting and provide exceptional torsional strength
- ¾” diameter pivot bushing secures the plow in place for proper alignment and reduces stress on the plow assembly
Scrape Lock
The FISHER® Scrape Lock system locks the plow in any position you put it in to give you a cleaner scrape, especially while back dragging. With the plow locked in place, Scrape Lock gives you the performance of a larger plow without the extra weight and without the need to push any extra buttons.
Universal Features
Trip Blade Protection
Accessories
LIGHT BAR KIT
Part NumbersPart Number
Light up the path in front of your TRAILBLAZER™ UTV plow with the all-new light bar accessory. The stylish LED headlamps brighten your way as you plow through the night.
CURB GUARDS (PAIR)
Part NumbersPart Number
Curbing can come out of nowhere sometimes. Protect your blade with a pair of genuine FISHER® curb guards. Constructed of abrasion-resistant material and designed to fit tight to the blade, these curb guards will allow you to plow along curbs with confidence and precision, without damaging your blade.
8" RUBBER DEFLECTOR
Part NumbersPart Number
Dress up your blade and improve functionality with a genuine FISHER® rubber deflector. Made from 2-ply, heavy-duty rubber and accented with the FISHER logo, this easy-to-install rubber deflector kit will provide improved visibility by deflecting snow forward instead of onto your windshield.
BLADE ANGLE STOPS
Part NumbersPart Number
Beef up your blade and prepare for extreme plowing conditions with genuine FISHER® Blade Angle Stops. Designed to transfer extreme impacts throughout the blade’s structure and reduce stress on the hydraulic rams, this kit comes with all of the necessary hardware and instructions for easy installation.
Specifications
| Specification | 84935 |
|---|---|
| Blade Width | 6' |
| Approx. Weight | 261 lb |
| Plowing Width | 5'4" Full Angle |
| Blade Height | 23.5" |
| Blade Gauge | 14 ga |
| Angling Rams | 1" x 7" |
| Cutting Edge | ¼" x 5" (Standard) |
| Specification | 84935 |
|---|---|
| Moldboard Options | High Strength or Powder-Coated Steel |
| Blade Type | Straight Blade |
| Vehicle Compatibility | Full Sized UTVs & Tractors |
| Trip Springs | 2 |
| Vertical Ribs | 4 |
| Mount Type | UTV Mounting System or Tractor Mount Kit |
Does this plow fit my vehicle?
Product Support & Resources
Buying Resources
Spec Sheet
DownloadServices & Support
Parts Lists
Installation Instructions
Owner's Manuals
Mechanic's Guide
Parts Finder
eSearch
Find service documentation for your TRAILBLAZER™ Heavy-Duty Straight Blade model. Search by part number, literature number, or keyword.
